Description
Every stage of the cycle, including water-fill, heating, sterilization, exhaust and drying, are microprocessor-controlled and completely automatic with these electronic models. The digital display continuously shows you temperature, pressure and running time. Four fully adjustable, single-button programs make these sterilizers easy to use and ensure reproducible runs. The handy battery backup ensures that all parameter settings and controls are retained in the event of a power failure. Electronic models are available with 9-, 10-, 12- and 15-inch diameter chambers.
Features
In addition to standard Tuttnauer sterilizer operating and safety features, all electronic models offer:
- Sterilization time to 59 minutes
- Temperature selection from 105 °C to 137 °C (221 °F to 279 °F)
- In-line particle filter to protect valves
- Electronic pressure and temperature sensors
- Low-water alarm - sounds when reservoir needs to be refilled
- Standby heating - keeps chamber warm for quicker cycles
Specifications
|
Power Supply
|
120V, 1400W, 12A
|
|
Heating Time (to 273F/134C)
|
20 min
|
|
Chamber Volume
|
5gal / 19liter
|
|
Chamber Dimensions (Dia. x Depth)
|
9 x 18 in / 22.9 x 45.7 cm
|
|
Tray Dimensions (W x D x H)
|
6.7 x 16.3 x 0.8 in / 17 x 41.5 x 2 cm
|
|
Overall Dimensions (W x D x H)
|
20 x 20 x 15 in / 50.8 x 50.8 x 38.1 cm
|
|
Weight
|
79 lb / 36 kg
|
Supplied with
3 Stainless Steel Trays
Additional Models
| Catalog Number |
Description |
| 16-1910-01 | Analog, 7.5L, 7" x 12" |
| 16-1910-02 | Analog, 19L, 9" x 18" |
| 16-1910-03 | Analog, 23L, 10" x 18" |
| 16-1910-04 | Analog, 65L, 15" x 20" |
| 16-1910-05 | Analog, 84L, 15" x 27" |
| 16-1910-06 | Analog, 34.4L, 12.2" x 18.5" |
| 16-1911-02 | Electronic, 19L, 9" x 18" |
| 16-1911-03 | Electronic, 23L, 10" x 18" |
| 16-1911-04 | Electronic, 65L, 15" x 20" |
| 16-1911-05 | Electronic, 84L, 15" x 27" |
| 16-1912-02 | Elec. w/Printer, 19L, 9" x 18" |
| 16-1912-03 | Elec. w/Printer, 23L, 10" x 18" |
| 16-1912-04 | Elec. w/Printer, 65L, 15" x 20" |
| 16-1912-05 | Elec. w/Printer, 84L, 15" x 27" |
| 16-1912-06 | EPA Model, 19L, 10" x 18" |
