Description
Ametek® Chatillon® Digital Force Gauge, 200 x 0.02 lbf, DFS2-200
Features:
- Compact, easy-to-use force gauge designed for basic and complex applications
- Use as either handheld or force test stand applications
- Large, easy-to-read, high resolution, full color dot matrix LCD display
- Measurement types include normal and peak readings, high/low limits, setpoints, pass/fail results, statistical results, load averaging, load comparisons, % and sharp break detection, loadcell actuation and direction
- Display can be inverted with results hidden from user
- Password protection for gauge set ups
- Single touch operation
- Dependable measurements
- Break detect for 2 kinds of breaks—sharp break can be used to detect whenever load measurement drops 5% from peak load or override sharp break and setup gauge with % break detector
- % break detector allows user to set drop percentage that is used to define break
Included:
- USB cable
- Carrying case
- Battery adapter/charger
- Testing accessories
- NIST Certificate of Calibration with data
Specifications:
| Model | DFS2-200 |
| Certification | NIST Certificate of Calibration with data |
| Maximum Overload | 150% of Rated Capacity |
| Tare Capacity | 10% of Rated Capacity |
| Resolution: | 10,000:1 |
| Peak Capture Rate | 10,000 Hz |
| Data Sampling | 10 KHz |
| Display Update Rate | 10 Hz |
| Data Save | Up to 100 Results |
| Battery Life | With Dimming ON and Bluetooth OFF: 20 Hours |
| With dimming OFF and Bluetooth OFF: 16 Hours | |
| With dimming ON and Bluetooth ON: 16 Hours | |
| With dimming OFF and Bluetooth ON: 12 Hours | |
| Operating Temperature | 41 °F to 110°F (5°C to 45°C) |
| Outputs | Bluetooth®, RS232, USB and +2V analog output |
| Multiple Language Interfaces | ,English, Spanish, French, German, Portuguese and Chinese |
| Instrument Weight | 1.5 lbs (0.7 kg) |
| Shipping Weight: | 4 lbs (2 kg) |
Specifications
| Capacity | 200 x 0.02 lbf / 100 x 0.01 kgf / 1000 x 0.1 N |
|---|---|
| Power | Universal Power, 120V/230V, Rechargeable Nickel Metal Hydride (supplied) |
| Accuracy | +0.1% of Full Scale - Non dedicate remote cells and torque sensors are 0.25% and 0.3% |
| Compliant/Standard | NIST Certificate of Calibration with data, IEC/ISO17025 optional |
| Operating Environment | 40 to 100 degrees F (4 to 38 degrees C), Relative humidity: 20 to 80% |
| Connectivity | Outputs: Bluetooth®, RS232, USB and +2V analog output |
| Dimensions | L x W x D: 7.5 x 2.86 x 1.62 in. (190 x 72.6 x 41.1 mm) |
| Weight | 1.5 lbs (0.7 kg) |
| Manufacturer | Ametek Chatillon |
| Model No | DFS2-200 |
| Warranty | 1 year |
