Colorimeter, Silica Checker, High Range 0 to 200 ppm (mg/L), Hanna Instruments, HI770

• Easier to use and more accurate than chemical test kits
• Adaptation of EPA Diazotization method
• ±2 ppm ±5% of reading accuracy
• 1 ppm resolution (200 points)
• Large, easy to read digits
• Auto shut off
• Dedicated to a single parameter
• Designed to work with HANNA's powder reagents
• Uses 10 mL glass cuvettes
• Small size, big convenience
• Weighing a mere 64 g (2.25 oz.), theChecker®HC easily fits into the palm of your hand or pocket
• Use for quick and accurate on the spot analysis
• Single button operation: zero and measure
• Operated by a single AAA battery
• 6-month warranty

Application:

• Aquaculture



Silica is the name given to silicon dioxide, SiO₂. Silicon, Si, is the most abundant element in the Earth's crust, 28% of it by weight. Silicon is never found free form in nature. In crystallized form it is only reactive under conditions of extremely high temperatures. Water and water vapor probably have little influence upon silicon solubility, because a protective surface layer of silicon dioxide is rapidly formed. Silicon binds with other elements to form various species of silica and silicate. The concentration of the soluble silica molecules are important to aquaculture because they influence (and limit) the growth of diatoms.  In most waters, the predominant form of dissolved silica is monosilicic acid, which incorporates 2 water molecules.

The HANNA HI 770 Checker®HC is accurate and affordable. This portable handheld colorimeter features a resolution of 1 ppm (200 points) and ±2 ppm ±5% of reading accuracy.

The contoured style of the HI 770 Checker®HC fit in your palm and pocket perfectly and the large LCD is easy to read. The auto shut off feature assures the battery life will not be drained if you forget to turn it off.

The HI 770 Checker®HC is simple to use. First, zero the instrument with your water sample. Next, add the reagents in order, respecting all the indications. Last, place the vial into the Checker®HC, press the operational button for about 3 seconds and the display will show the countdown prior to the measurement or, alternatively, wait for 2 minutes after last reagent adding and press operational button. The Checker®HC displays concentration in ppm of Silica as SiO₂.



90-2619-01	Free Chlorine Checker®HC HI701
90-2619-02	Total Chlorine Checker®HC HI 711
90-2619-03	Free Phosphate Checker®HC HI 713
90-2619-04	Free Iodine Checker®HC HI 718
90-2619-05	Free Iron Checker®HC HI 721
90-2619-06	Low Range Fluoride Checker®HC HI 729
90-2619-07	Calcium Checker®HC HI 758
90-2619-08	High Range Silica Checker®HC HI 770
90-2619-09	Color of Water Checker®HC HI 727
90-2619-12	Ultra Low Range Phosphorus Checker®HC HI 736
90-2619-13	Alkalinity Checker®HC HI 755
90-2619-14	Ultra Low Range Nitrite Checker®HC HI 764
90-2619-15	High Range Phosphorus Checker®HC HI 706
90-2619-16	High Range Nickel Checker®HC HI 726
90-2619-17	High Range Phosphate Checker®HC HI 726
90-2619-18	High Range Chromium VI Checker®HC HI 717
90-2619-39	High Range Ammonia Checker®HC HI 733
90-2619-60	Low Range Ammonia Checker®HC HI 700
90-2619-90	Ultra High Range Total Chlorine Checker®HC HI 771
90-2619-93	Ultra Low Range Total Chlorine Checker®HC HI 761
