| Capacity x Readability |
g |
122 x 0.001 |
| oz |
4.30 x 0.00005 |
| lb |
0.268 x 0.000005 |
| lb-oz |
0 lb. 4.30 oz x 0.01 oz. |
| ozt |
3.92 x 01.00005 |
| ct |
610 x 0.005 |
| dwt |
78.6 x 0.001 |
| GN |
1882 x 0.02 |
| Counting Mode |
Min. Unit Mass |
0.001 g |
| # of Samples |
5 , 10, 25, 50, or 100 pieces |
| Percent Mode |
Min. 100% Ref. Mass |
0.100 g |
| Min. 100% Display |
0.01%, 0.1%, 1% (depends on the reference mass stored |
| Reapeatability (Std. Deviation) |
0.001 g |
| Linearity |
± 0.002 g |
| Stabilization Time (typically set at FAST) |
Approx. 1 second |
| Sensitivity Drift (10 °C to 30 °C) |
± 2 ppm / °C |
| Operating Temp |
5 °C to 40 °C (41 °F to 104 °F), 85% RH or less (No condensation) |
| Display Type |
Vacuum Fluorescent Display (VFD) |
| Display Refresh Rate |
5 times / second, 10 times / second, or 20 times / second |
| Std. Serial Interface |
RS-232C Interface |
| Weighing Pan |
130 mm |
| External Calibration |
100 g500 g |
| AC Adaptor |
Confirm tht the adaptor type is correct for the local voltage and power receptacle |
| Power Consumption |
Approx. 11 VA (supplied to the AC Adaptor) |
| External Dimensions |
193 (W) x 262.5 (D) x 84.5 (H) mm |
| Net Weight |
Approx. 2.5 kg |
