Description
Advantec MFS™ Glass Fiber Filter Grade GB100R 95 Weight 22 mm, 0.6 µm Nonsterile, 100/PkFeatures:
¹ Flow time is the time in seconds to filter 100 mL of distilled water at 20 °C under pressure supplied by a 10 cm water column through a 10 cm² section of filterOther Sizes of Grade GB100R Available:
- Dense
- Highly resistant to chemical attack, biologically inert
- Easily sterilized—can be baked or autoclaved
- Store indefinitely—unaffected by humidity
- Use as a prefilter to extend membrane life
- Water/air pollution analysis
- Liquid clarification
- Cell harvesting
| Grade | GB100R |
| Applications/Characteristics | High and low volume aerosols for airborne dust and metal contaminants; Low trace metal content of AS, Pb, and Cd; DNA/RNA and protein precipitates |
| Weight, g/m² | 95 |
| Thickness, mm | 0.40 |
| Nominal Rating, µm | 0.6 |
| Diameter, mm | 25 |
| Water Flow Time ¹, sec | 15 |
| Gas Collection Efficiency, % at 0.3 µm DOP | 99.99 |
| Pressure Drop, mm H20/5 cm/sec | 31 |
| Binder | None |
| Maximum Operating Temperature, °C | 500 |
| Conversions | |
| Whatman | EPM2000 |
| Schleicher & Schuell | 1HV |
| Pall | A/E (use for air) |
| Millipore | N/A |
| Ahlstrom | N/A |
| Cat. No. | Mfg. No. | Filter Diameter, mm |
| 90-7466-20 | GB100R25MM | 25 |
| 90-7466-21 | GB100R47MM | 47 |
| 90-7466-22 | GB100R50MM | 50 |
| 90-7466-24 | GB100R90MM | 90 |
