Description
Laboratory Plate Grinding Mill Crusher, 230 V/1 Ph/50 Hz, Model 4-E
Features:
- Grinding unit construction is sturdy cast iron, heavily coated for food handling
- Grinding unit can be removed and disassembled for cleaning without the use of tools
- Grinding plates are made of hard iron alloy designed for clog resistance and long life
- Plate clearance easily adjusted by hand to change mesh
- Rigid cast aluminum base and bearing for minimum weight.
- 3- Point rubber pads for stability.
- Low current requirements, needs no special wiring.
- Choice of 4-B Plates for fine grinding or 4-CS Plates for coarse grinding.
- Choice of Tooth Feed for dry grinding or Worm Feed for wet or oily grinding
Typical Applications:
- Coal
- Ores
- Soil tests
- Lab sample preparation
- Soft or hard grains for cereal & bread
- Corn
- Coffee
- Pharmaceuticals
- Chemicals
- Nut meats
- Peanuts
- Soil tests
- Iron turnings
Specifications:
| Power Requirements:† | 230 Volt, 1 Phase, 50 Cycle |
| Capacity of Hopper: | 50 cu.in. (approx. 2 lbs.) |
| Table Top to Discharge: | 6 in. |
| Diameter of Grinding Plates: | 4 in. |
| Output Capacity:* | 40 lbs. per hr. |
| Maximum Fineness:* | 75 to 100 mesh |
†Other voltages and frequencies available
*Output Capacity & Fineness of Grinding varies with material.
Specifications
| Power | 230 V/1 Ph/50 Hz |
|---|---|
| Application | Fine laboratory sample preparation |
| Dimensions | 25 in. L x 8 in. W x 12 in. H |
| Weight | 55 lbs |
| Manufacturer | QCG Systems LTD |
| Model No | S-4E-2-5/6TC |
