Description
Fast heat-up rates - Powerful open coil heating elements and a forward curved fan deliver faster heat-up rates and short processing times.
Precise digital controls - Digital controls regulate temperatures within tight tolerances. A 3/4 (1.9cm) LED panel displays temperatures in large, bright, easy-to-read numbers. Temperatures can be reported in either Fahrenheit or Celsius.
Reliable, trouble-free performance - The LBB is designed and manufactured to provide years of dependable service. The fan and heater are top-mounted to prevent damage from spills. When spills do occur, the corrosion-resistant stainless steel interior and nickel plated shelves clean up easily. The motor is permanently lubricated and virtually maintenance free. And Despatch warrants the heater performance for a full five years the best warranty in the industry.
Every LBB benchtop oven is UL and C-UL listed, and receives a thorough performance test before shipping.
Forced convection for excellent temperature uniformity - A top-mounted fan draws air through the heater coils and propels it back to the chamber through plenums in the side walls, resulting in consistent, uniform temperatures.
-
Temperatures up to 204°C (400°F)
-
Forced convection from top-mounted fan and plenums on sides of chamber
-
Digital control with 3/4 (1.9cm) LED display
-
304 stainless steel interior
-
5-year heater warranty
-
High-limit control
-
Nickel plated shelves - by model rated from 50 to 200lbs (23 to 91kg)
-
UL and C-UL listed
|
PHYSICAL SPECIFICATIONS
|
|
|
Chamber size (w x d x h) *clear opening width reduced
by 1½"" due to ¾"" shelf supports on each side.
|
24 x 14 x 22 in.
61 x 36 x 56 cm
|
|
Capacity in cubic feet (liters)
|
4.3 (122)
|
|
Overall size (w x d x h) *depth includes exhaust port.
|
30 x 20.5 x 36.5 in.
76 x 52 x 93 cm
|
|
Electrical (50/60Hz. 1ph) Volts / Amps / Heater kW
|
120 / 15.3 / 1.6
|
|
Number of shelves provided
|
2
|
|
Maximum number of shelves
|
10 on 2in. centers
|
|
Cord and plug
|
20 amp
|
|
Number of doors
|
1
|
|
Approximate net weight
|
195 lbs. (88kg)
|
|
Approximate shipping weight
|
270 lbs. (121kg)
|
|
FUNCTIONAL SPECIFICATIONS
|
|
|
Time to temp with no load (40°C to 150°C)
|
17 minutes
|
|
Time to temp with no load (40°C to 204°C)
|
30 minutes
|
|
Recovery time after door open 1 min. (150°C)
|
2 minutes
|
|
Recovery time after door open 1 min. (204°C)
|
4 minutes
|
Specifications
| Manufacturer | Despatch |
|---|---|
| Model No | LBB 1-43A-1 |
