Description
Parr Instrument Company® Parr 6520EF Water Handling System, 230 V/50-60 Hz
The Parr 6520EF is a closed loop system. The bucket and jacket water is recycled to a holding tank and circulated through a cooler to bring the water back to the desired starting temperature. The 6520EF Water Recirculation System includes an integral thermoelectric cooler and eliminates the need for a stand alone cooler. Users who wish to operate independently from tap water and drains or where water supplies may be high in mineral contents that over time can deposit in the calorimeter will prefer this mode of operation. The system has 4 L reservoir.
Features
- Includes integral thermoelectric cooler that eliminates need for stand alone cooler
- Water Recirculation system is equipped with low temperature limit controller to prevent freezing
- Unit displays temperature of water
- Convenient means to operate Parr 6300 calorimeter when aconstant supply of good quality tap water is not available
- Use of distilled or deionized water prevents build up of mineral deposits—water must be below 85 ppm total hardness
- Less expensive because tap water is not being used
Supplied with:
- Includes an integral thermoelectric cooler that eliminatesthe need for a stand alone cooler
Additional Models
| 90-4062-11 | Model 6510EA Water Handling System, 115V |
| 90-4062-12 | Model 6510EF Water Handling System, 230V |
| 90-4064-11 | Model 1564EA Water Recirculation System, 115V |
| 90-4064-12 | Model 1564EF Water Recirculation System, 230V |
| 90-4135-03 | Model 1563EA Water Handling System 115V |
| 90-4135-04 | Model 1563EF Water Handling System 230V |
| 90-4064-09 | Model 6520EA Water Handling System, 115V |
| 90-4146-01 | Model 1552EA Water Cooler, 115V |
| 90-4146-02 | Model 1552EF Water Cooler, 230V |
