Description
Parr Instrument Company® Water Cooler, 230 V/ 50-60 Hz, 1552EF
Features:
- Separate water cooler must be used with 1563A Water Handling System or 1564 Water Recirculating System to compensate for heat introduced in each calorimetric test
- Parr®1552 Water Cooler is recommended for this purpose
- Water cooler removes heat produced in combustion process from system
- 1552 Water Cooler produces 6.5 gal/hr of cold water between 5 and 10 degrees C
- Speed that calorimeter will recycle between tests is function of temperature of incoming tap water
- Performance will slow noticeably above 20 degrees C and will become sluggish above 25 degrees C
- Water Cooler can be installed on inlet line to assure adequate cooling water and faster recycle times
- One 1552 Water Cooler will supply up to four Model 6300 Calorimeters
Additional Models:
| 90-4062-11 | Model 6510EA Water Handling System, 115V |
| 90-4062-12 | Model 6510EF Water Handling System, 230V |
| 90-4064-11 | Model 1564EA Water Recirculation System, 115V |
| 90-4064-12 | Model 1564EF Water Recirculation System, 230V |
| 90-4135-03 | Model 1563EA Water Handling, System 115V |
| 90-4135-04 | Model 1563EF Water Handling, System 230V |
| 90-4064-09 | Model 6520EA Water Handling, System, 115V |
| 90-4135-09 | Model 6520EF Water Handling, System, 230V |
| 90-4146-01 | Model 1552EA Water Cooler, 115V |
