Precision Balance, Toploader Model FX-200iWP, Waterpoof, 220 g x 0.001 g, External Calibration & Breeze Break
Roll over image to zoom in Click on image to zoom
Precision Balance, Toploader Model FX-200iWP, Waterpoof, 220 g x 0.001 g, External Calibration & Breeze Break

Precision Balance, Toploader Model FX-200iWP, Waterpoof, 220 g x 0.001 g, External Calibration & Breeze Break

Item: 90-1709-05-EA
UOM: EA (1)
Price:
$1,466.25

Description


The FX-iWP is the first Water proof/Dust proof, 0.001 g compact precision balance. The FX-iWP incorporates the reduced size Compact Super-Hybrid Sensor (SHS), which continues to provide quick (one second) readings with high precision. The new Statistical Calculation Function (SCF) provides statistical data display or output of weighed samples. Six models are available from 120 g x 0.001 g to 3200 g x 0.01 g.  The FX-200iWP has a capacity of 220g and a readability of 0.001g. Features
  • IP65 Water proof/Dust Proof
  • Compact SHS (Super Hybrid Sensor) 1 Second Stabilization
  • Multiple Weighing Units (g, oz, lb, lb-oz, ozt, ct, mom, dwt, GN, tl, tol, mes, pcs, % and MLT)
  • SCF-Statistical Calculation Function
  • Quick USB Interface (FXi-02)
  • Standard RS-232C Interface
  • Comparator Function
  • Digital Calibration Function
  • LAN-Ethernet Interface (FXi-08) with WINCT-Plus Software
  • 5 Year Warranty
  • Operating Temp:  5°C to 40ºC (41°F to 104°F), 85% RH or less (No condensation)
  • Display Type:  Vacuum Fluorescent Display (VFD)
  • External Dimensions:  193 (W) x 262.5 (D) x 84.5 (H) mm
  • Weighing Pan Dimensions:  130mm Diameter
Specifications

Capacity x Readability
g
220 x 0.001
oz 7.76 x 0.00005
lb 0.485 x 0.000005
lb-oz 0 lb, 7.76 oz x 0.01 oz
ozt 7.07 x 0.00005
ct 1100 x 0.005
dwt
141.7 x 0.001
GN 3395 x 0.02
Counting Mode
Min.Unit Mass
0.001g
# of Samples
5 , 10, 25, 50 or 100 pieces
Percent Mode
 Min. 100% Ref. Mass
0.100g
Min. 100% Display
0.01%, 0.1%, 1% (depends on the reference mass stored)
Repeatability (Std. Deviation)
0.001g
Linearity
±0.002g
Stabilization Time (typically set at FAST)
Approx. 1 Second
Sensitivity Drift (10 °C to 30 °C)
±2ppm / °C
Operating Temp
5°C to 40°C (41°F to 104°F), 85% RH or less (no condensation)
Display type
Vacuum Fluorescent Display (VFD)
Display refresh Rate
5 times / second, 10 times / second or 20 times / second
Std. Serial Interface
RS-232C Interface
Weighing Pan
130mm
External Calibration
200g  /  100g
AC Adapter
Adapter type for local voltage and power receptacle
Power Consumption
Approx. 11VA (supplied to the AC adapter)
External Dimensions
193 (W) x 262.5 (D) x 84.5 (H) mm
Net Weight
Approx. 2.5kg



Specifications

Manufacturer A&D Weighing
Model No FX-200iWP
