Precision Topload Balance, A&D FX-200i, 220 g Capacity x 0.001 g Readability
Roll over image to zoom in Click on image to zoom
Precision Topload Balance, A&D FX-200i, 220 g Capacity x 0.001 g Readability

Precision Topload Balance, A&D FX-200i, 220 g Capacity x 0.001 g Readability

Item: 90-1709-09-EA
UOM: EA (1)
Price:
$1,109.50

Description


A&Ds FX-i Series entry level precision balance is a full-featured 0.01g to 1mg readability balance at a very affordable price. The patented Compact Super Hybrid Sensor is at the heart of this unit and provides fast, one-second weighing response time.  The FX-i also contains a specially designed internal shock absorber that offers protection from the adverse effects of vertical or transverse overloading. Legal-for-trade models (NTEP and Measurement Canada) are also available.

Product Features
  • Compact SHS (Super Hybrid Sensor) 1 Second Stabilization
  • Bright vacuum flourescent display
  • Multiple Weighing Units (g, oz, lb, lb-oz, ozt, ct, mom, dwt, GN, tl, tol, mes, pcs, % and MLT)
  • SCF-Statistical Calculation Function
  • Quick USB Interface (FXi-02)

Specifications

Capacity x Readability
g
220 x 0.001
oz 7.76 x 0.00005
lb 0.485 x 0.000005
lb-oz 0 lb, 7.76 oz x 0.01 oz
ozt 7.07 x 0.00005
ct 1100 x 0.005
dwt
141.7 x 0.001
GN 3395 x 0.02
Counting Mode
Min.Unit Mass
0.001g
# of Samples
5 , 10, 25, 50 or 100 pieces
Percent Mode
Min. 100% Ref. Mass
0.100g
Min. 100% Display
0.01%, 0.1%, 1% (depends on the reference mass stored)
Repeatability (Std. Deviation)
0.001g
Linearity
±0.002g
Stabilization Time (typically set at FAST)
Approx. 1 Second
Sensitivity Drift (10 °C to 30 °C)
±2ppm / °C
Operating Temp
5°C to 40°C (41°F to 104°F), 85% RH or less (no condensation)
Display type
Vacuum Fluorescent Display (VFD)
Display refresh Rate
5 times / second, 10 times / second or 20 times / second
Std. Serial Interface
RS-232C Interface
Weighing Pan
130mm
External Calibration
200g  /  100g
AC Adapter
Adapter type for local voltage and power receptacle
Power Consumption
Approx. 11VA (supplied to the AC adapter)
External Dimensions
193 (W) x 262.5 (D) x 84.5 (H) mm
Net Weight
Approx. 2.5kg




Specifications

Manufacturer A&D Weighing
Model No FX-200i
