Description
Saint Gobain Performance® Tubing, Food, Milk and Dairy, 3/16 in. x 5/16 in., AAA00012
Features:
- Smooth, non-porous bore will not trap particulates or promote bacterial growth
- Resistant to harsh alkaline cleaners and sanitizers
- Excellent alternative to rigid piping systems
- Contains no BPA or phthalates
- Readily bends minimum radius of 5/8 in. to accommodate abrupt corners and obstructions, requiring minimum couplings and fittings
- Glass-like clarity allows viewing product flow
Specifications
| Range | Maximum pressure: 43 psi at 73 degrees F |
|---|---|
| Range | Temperature: -32 to 165 degrees F |
| Range | Maximum vacuum: 29.9 in. Hg |
| Material | Thermoplastic elastomer (TEP) |
| Compliant/Standard | 3-A Sanitary Standards; FDA CFR Part 175.300; NSF 51 |
| Dimensions | 3/16 inside diameter x 5/16 outside diameter x 1/16 wall thickness |
| Manufacturer | Saint Gobain Performance |
| Model No | AAA00012 |
