Description
Hanna Instruments® Chlorine, pH, ORP, and Temperature Analyzers, PCA320U-1
Features:
- Hanna PCA300 series chlorine analyzers continuously monitor, control, and adjust chlorine content and pH of sample stream
- From drinking and wastewater treatment to pool and spa sanitation, monitoring chlorine levels has an important bearing on public health as well as ROI and efficiency for heating system and industrial applications
- 4 models available for monitoring chlorine, pH, and ORP levels.
- Separate alarms can be set for chlorine, pH, ORP and temperature controls
- User-friendly interface simplifies setup and maintenance
- Four chlorine levels can be adjusted by the operator: proportional dosing setpoint, two alarm setpoints, and minimum level for dosing
- Three pH levels can be adjusted by operator: dosing setpoint and two alarm setpoints
- Two alarm levels can be set for temperature and ORP
- All alarms can be enabled or disabled
- System also offers overdosing protection that generates alarm if something within system is not working properly
- System will stop processes until the error is corrected by user
- Stores up to 3500 readings (at least 7 days at 3 minutes sampling interval) that can be available for consulting or downloading
- Logged records contain time stamp, full information about parameter values and alarm status at time
- Five analog outputs of 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA or 0-20 mA are available to drive external devices, including connection to SCADA systems
- Analog output is fully programmable and can be proportional with chlorine concentration, pH, ORP or temperature value
- Limits of analog output are selectable for each parameter
- Control time cycle that can be set by user according to dimensions of controlled system
- Measurement process, dosing commands, and alarms can be performed according to this time cycle
- Range of cycle timing is from 3 to 90 minutes
- Unit can be wall mounted for easy accessibility
- Housing offers excellent chemical, mechanical and temperature resistance
Specifications:
| CHLORINE MEASUREMENT AND DOSING (All models) | |
| Range | 0.00 to 5.00 mg/L |
| Resolution | 0.01 mg/L |
| Accuracy | ± 8% or ± 0.05 mg/L whichever is greater |
| Calibration | 1 point |
| Minimum detectable level | 0.05 mg/L |
| Sampling rate | adjustable from 3 to 90 minutes |
| Dosage | proportional relay or 4-20 mA output |
| Delta (Δ) | selectable 0.1 to 5 mg/L |
| pH MEASUREMENT AND DOSING (PCA320, PCA330 and PCA340) | |
| Range | 0.00 to 14.00 pH |
| Resolution | 0.01 pH |
| Accuracy | ± 0.05 pH |
| Calibration | one or two points or in-line calibration |
| Dosing rate | adjustable from 3 to 120 seconds |
| Dosage | On/Off or proportional, relay or 4-20 mA output |
| Delta (Δ) | selectable from 0.10 to 2.00 pH |
| Hysteresis | selectable from 0.05 to 2.00 pH |
| TEMPERATURE MEASUREMENT (PCA320, PCA330 and PCA340) | |
| Range | 5.0 to 75.0 °C (41.0 to 167.0 °F) |
| Resolution | 0.1 °C (0.1 °F) |
| Accuracy | ± 0.5 °C (± 1.0 °F) |
| OTHERS (All models) | |
| Recorder output | 0-10 mV, 0-100 mV, 0-1 V, 4-20 mA, 0-20 mA (PCA310, PCA320, PCA330) 4-20 mA, 0-20 mA (PCA340) |
| Serial communication | RS485, galvanic separated |
| Baud rate | 1200; 2400; 4800; 9600 bps |
| Display character | LCD 4 lines x 20 characters |
| Languages | English, Italian, Portuguese, Spanish |
| Log | 3500 log records |
| GSM alarm | 2 numbers, alarm SMS, info SMS, warning SMS |
| Alarm relay | SPDT contact with 5A, 230V resistive load |
| Dosing relays | SPST contact with 5A, 230V resistive load |
| System error relay | SPST contact with 5A, 230V resistive load |
| Sample inlet pressure | 0.07 to 4 bar |
| Sample flow rate | 100 to 300 mL/min |
| Sample temperature | 5 to 40 °C |
| Sample inlet | 12 mm (1/2”) male NPT fitting |
| Sample outlet | 12 mm (1/2”) male NPT fitting |
| Drain connection | 10 mm (3/8”) barb |
| Process pH/temp probe | HI1005 |
| Process ORP probe | HI2008 |
| Power supply | 115 VAC ± 10% or 230 VAC ± 10%; 50-60 Hz; 20 VA |
| Case | NEMA-4X |
Specifications
| Range | Chlorine: 0.00 to 5.00 mg/L |
|---|---|
| Range | Temperature: 5.0 to 75.0 degrees C (41.0 to 167.0 degrees F) |
| Range | pH: 0.00 to 14.00 pH |
| Power | 115 VAC ± 10% or 230 VAC ± 10%; 50-60 Hz; 20 VA |
| Manufacturer | Hanna Instruments |
| Model No | PCA320U-1 |
