Description
Dwyer-Omega® RATE-MASTER® Flowmeter, Air, 10 L/min to 100 L/min, Polycarbonate, RMA-25-SSV
Features:
- General use, direct reading precision flowmeters suitable for both gas and liquid applications
- Flowmeter bodies can be instantly interchanged, allowing piping to remain undisturbed allowing interchangeability of ranges and easy cleaning
- Direct reading scale with presence of scale graduations on indicating tube saves time by eliminating troublesome conversions
- Durable, shatter-proof polycarbonate body for long life
- Special integral flow guides that stabilize float movement increase reading accuracy
- Stainless steel backbone reduces installation damage and cost by absorbing piping torque
- Precision injection molding around precision tapered pin produces high repeatability
- Representative image — actual product may be different
Specifications
| Range | Flow: 10 to 100 LPM air |
|---|---|
| Range | Scale: 2 in. / 51 mm |
| Range | Liquid Flow, Maximum: 0 m3/s |
| Range | Pressure: 100 psi / 6.9 bar |
| Material | Polycarbonate, aluminum and Buna-N with stainless steel valve |
| Accuracy | +/- 4% |
| Compliant/Standard | EU Directive 2011/65/EU (RoHS II) |
| Operating Environment | Maximum temperature: 130 degrees F / 54 degrees C |
| Connectivity | NPT female connector: 1/8 in. |
| Weight | 4 oz / 113.4 g |
| Manufacturer | DwyerOmega |
| Model No | RMA-25-SSV |
